R5F21262SDFP#U0
| Manufacturer | |
| Description | MCU 16-bit R8C CISC 8KB Flash 3.3V/5V 32-Pin LQFP Tray IC MCU 16BIT 8KB FLASH 32LQFP |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Standard Package Name | QFP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | Approval Agency | No |
Electrical
| Speed | 20 MHz | RAM Size | 512 byte |
| Core Size | 16-Bit | Core Type | R8C |
| Frequency | 20 MHz | Interface | I2C/UART |
| Clock Rate | 20 | Number of I/O | 25 |
| Number of Bits | 10 | Voltage Rating | 3 |
| Watchdog Timer | 1 | Data Converters | A/D 12x10b |
| Oscillator Type | Internal | Serial Protocol | 2 |
| Voltage - Supply | 3.3|5 V | Program Memory Size | 8 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 12 |
| Voltage - Supply (Min) | 3 V | Power Dissipation (Max) | 500 mW |
| Voltage - Supply (Vcc/Vdd) | 2.2 V ~ 5.5 V | ||
Mechanical
| Width | 7 | Packaging | Tray |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Package / Case | 32LQFP | Package Cooled | LQFP |
| Length - Overall | 7 | Package Quantity | LQFP |
| Number of Positions | 32 | Shell Size - Insert | 1.4 |
| Supplier Device Package | 32-LQFP (7x7) | Number of Cores/Bus Width | 16 Bit |
Product Info
| Protocol | 1 | On-Chip RAM | 12-chx10-bit |
| Peripherals | LED, POR, Voltage Detect, WDT | Architecture | CISC |
| Connectivity | I²C, LIN, SIO, SSU, UART/USART | Programmable | Yes |
| Core Processor | R8C | Number of Timers | 4 |
| RF Family/Standard | R8C | DigiKey Programmable | Yes |
| Printed Circuit Board | 32 | ||
Environmental
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85C |
