R5F211B4SP#U0
| Manufacturer | |
| Description | MCU 16-bit R8C CISC 16KB Flash 3.3V/5V 20-Pin LSSOP Tube MCU 16-bit R8C R8C CISC 16KB Flash 3.3V/5V 20-Pin LSSOP Tube R5F211B4SP#U0 IC MCU 16BIT 16KB FLASH 20SSOP R5F211B4SP#U0, 16 bit Microcontroller R8C/1B 20MHz 2, 16kb Flash, 1kb RAM, I2C 20-Pin LSSOP MCU 16-Bit R8C CISC 16KB Flash 3.3V/5V 20-Pin LSSOP Tube IC, MCU, 16BIT, R8C/1B, 20SSOP IC MCU 16BIT 16KB FLASH 20LSSOP Renesas Electronics R8C 系列 16 bit R8C/1B MCU, 20MHz, 16 kB, 2 kB ROM 闪存, 1 kB RAM, 20针 LSSOP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1 | Unit Pack | 0 |
| Standard Package | Rail / Tube | Standard Package Name | TSSOP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Approval Agency | No | ||
Electrical
| Speed | 20 MHz | Timer | 1 x 16 bit, 2 x 8 bit |
| RAM Size | 1 KB | Core Size | 16-Bit |
| Core Type | R8C | Interface | I2C/UART |
| Clock Rate | 20 | Memory Size | 2 KB |
| Number of I/O | 13 | Number of Bits | 10 |
| Voltage Rating | 2.7 → 5.5 V | Watchdog Timer | 1 |
| Clock Frequency | :20MHz | Data Converters | A/D 4x10b |
| Frequency - Max | 20MHz | Oscillator Type | Internal |
| Serial Protocol | 2 | Voltage - Supply | 3.3|5 V |
| Resolution (Bits) | 10bit | Number of Channels | 0 |
| Program Memory Size | 16 KB | Program Memory Type | Flash |
| Number of ADCs / DACs | 4 | Voltage - Supply (Min) | 5.5 |
| Frequency (Center/Band) | 16 bit, 8 bit | Power Dissipation (Max) | 300 mW |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 5.5 V | ||
Mechanical
| Width | 4.5mm | Height | 1.15mm |
| Length | 6.6mm | Weight | 0.000299 |
| Packaging | Tube | Lead Style | Gull-wing |
| Termination | :SMD | Mounting Type | Surface Mount |
| Number of Pins | :20 | Package / Case | 20LSSOP |
| Package Cooled | LSSOP | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 6.5 | Package Quantity | LSSOP |
| Size / Dimension | 6.6 x 4.5 x 1.15mm | Number of Positions | 20 |
| Shell Size - Insert | 1.15 | Supplier Device Package | 20-LSSOP |
| Number of Cores/Bus Width | 16 Bit | ||
Product Info
| USB | 0 | Protocol | 1 |
| Base Unit | :M16C/R8C/Tiny | Flash Size | :16KB |
| On-Chip RAM | 4-chx10-bit | Peripherals | LED, POR, Voltage Detect, WDT |
| Architecture | CISC | Connectivity | I²C, SIO, SSU, UART/USART |
| Core Processor | R8C | Number of Timers | 3 |
| Controller Series | :R8C/1x | RF Family/Standard | R8C |
| DigiKey Programmable | Yes | Printed Circuit Board | 20 |
| Number of A/D Converters | :4 | ||
Environmental
| Operating Temperature | -20 to 85 °C | ||
