R5F211A1DSP#U0
| Manufacturer | |
| Description | MCU 16-bit R8C CISC 4KB Flash 3.3V/5V 20-Pin LSSOP Tube IC MCU 16BIT 4KB FLASH 20SSOP |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Standard Package Name | TSSOP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Approval Agency | No | ||
Electrical
| Speed | 20 MHz | RAM Size | 384 byte |
| Core Size | 16-Bit | Interface | I2C/UART |
| Clock Rate | 20 | Number of I/O | 13 |
| Number of Bits | 10 | Voltage Rating | 3 |
| Watchdog Timer | 1 | Data Converters | A/D 4x10b |
| Oscillator Type | Internal | Serial Protocol | 2 |
| Voltage - Supply | 3.3|5 V | Program Memory Size | 4 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 4 |
| Voltage - Supply (Min) | 5.5 | Power Dissipation (Max) | 300 mW |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 5.5 V | ||
Mechanical
| Width | 4.4 | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Package / Case | 20LSSOP | Length - Overall | 6.5 |
| Package Quantity | LSSOP | Number of Positions | 20 |
| Shell Size - Insert | 1.15 | Number of Cores/Bus Width | 16 Bit |
Product Info
| Protocol | 1 | On-Chip RAM | 4-chx10-bit |
| Peripherals | LED, POR, Voltage Detect, WDT | Architecture | CISC |
| Connectivity | I²C, SIO, SSU, UART/USART | Core Processor | R8C |
| Number of Timers | 3 | RF Family/Standard | R8C |
| DigiKey Programmable | Yes | Printed Circuit Board | 20 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
