M306N5FCTFP#U0
| Manufacturer | |
| Description | MCU 16-bit R8C CISC 128KB Flash 5V 100-Pin LQFP Tray IC MCU 16BIT 128KB FLASH 100QFP |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Standard Package Name | QFP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Speed | 20 MHz | RAM Size | 5 KB |
| Core Size | 16-Bit | Interface | I2C/IEBus/UART |
| Clock Rate | 20 | Number of I/O | 87 |
| Number of Bits | 10 | Voltage Rating | 4.2 |
| Data Converters | A/D 26x10b; D/A 2x8b | Number of DAC's | 2 |
| Oscillator Type | Internal | Voltage - Supply | 5 V |
| Program Memory Size | 128 KB | Program Memory Type | Flash |
| Number of ADCs / DACs | 26 | Voltage - Supply (Min) | 5.5 |
| Power Dissipation (Max) | 700 mW | Number of Bits per Element | 8 |
| Voltage - Supply (Vcc/Vdd) | 4.2 V ~ 5.5 V | ||
Mechanical
| Width | 14 | Packaging | Tray |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Package / Case | 100LQFP | Length - Overall | 14 |
| Package Quantity | LQFP | Number of Positions | 100 |
| Shell Size - Insert | 1.4 | Supplier Device Package | 100-QFP (14x20) |
| Number of Cores/Bus Width | 16 Bit | ||
Product Info
| On-Chip RAM | 26-chx10-bit | Peripherals | DMA, WDT |
| Architecture | CISC | Connectivity | CAN, I²C, IEBus, SIO, UART/USART |
| Core Processor | M16C/60 | Number of Timers | 11 |
| RF Family/Standard | R8C | DigiKey Programmable | Yes |
| Printed Circuit Board | 100 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
