M30260F3AGP#U3A
| Manufacturer | |
| Description | MCU 16-bit R8C CISC 24KB Flash 3.3V/5V 48-Pin LQFP IC MCU 16BIT 24KB FLASH 48LQFP |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | M30260F3AGPU3A | Standard Package | Trays |
| Standard Package Name | QFP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | Approval Agency | No |
Electrical
| Speed | 20 MHz | RAM Size | 1 KB |
| Core Size | 16-Bit | Core Type | R8C |
| Frequency | 20 MHz | Interface | UART |
| Clock Rate | 20 | Number of I/O | 39 |
| Number of Bits | 10 | Voltage Rating | 3 |
| Watchdog Timer | 1 | Data Converters | A/D 12x10b |
| Frequency - Max | 20 MHz | Oscillator Type | Internal |
| Serial Protocol | 3 | Voltage - Supply | 3.3|5 V |
| Program Memory Size | 24 KB | Program Memory Type | Flash |
| Number of ADCs / DACs | 12 | Voltage - Supply (Min) | 3 V |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 5.5 V | ||
Mechanical
| Width | 7 | Packaging | Tray |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Package / Case | 48LQFP | Package Cooled | LQFP |
| Length - Overall | 7 | Package Quantity | LQFP |
| Number of Positions | 48 | Shell Size - Insert | 1.4 |
| Supplier Device Package | 48-LQFP (7x7) | Number of Cores/Bus Width | 16 Bit |
Product Info
| On-Chip RAM | 12-chx10-bit | Peripherals | DMA, PWM, Voltage Detect, WDT |
| Architecture | CISC | Connectivity | I²C, IEBus, SIO, UART/USART |
| Programmable | Yes | Core Processor | M16C/60 |
| Number of Timers | 8 | RF Family/Standard | R8C |
| DigiKey Programmable | Yes | Printed Circuit Board | 48 |
Environmental
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85C |
