DF2319EVTE25V
| Manufacturer | |
| Description | MCU 16-bit H8S CISC 512KB Flash 3.3V 100-Pin TQFP IC MCU 16BIT 512KB FLASH 100TQFP |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | HD64F2319EVTE25V | Standard Package | Trays |
| Standard Package Name | QFP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | Approval Agency | No |
Electrical
| Speed | 25 MHz | Channels | 70 |
| RAM Size | 8 KB | Core Size | 16-Bit |
| Core Type | H8S | Frequency | 25 MHz |
| Interface | SCI | Clock Rate | 25 |
| Memory Type | Flash | Number of I/O | 70 |
| Number of Bits | 10 | Voltage Rating | 2.7 |
| Data Converters | A/D 8x10b; D/A 2x8b | Number of DAC's | 2 |
| Oscillator Type | Internal | Voltage - Supply | 3.3 V |
| Program Memory Size | 512 KB | Program Memory Type | Flash |
| Number of ADCs / DACs | 8 | Voltage - Supply (Min) | 2.7 V |
| Voltage - Supply, Digital | 2.7 V ~ 3.6 V | Number of Bits per Element | 8 |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 3.6 V | ||
Mechanical
| Width | 14 | Packaging | Tray |
| Lead Style | Gull-wing | Core Diameter | 16-Bit |
| Mounting Type | Surface Mount | Package / Case | 100TQFP |
| Package Cooled | TQFP | Length - Overall | 14 |
| Package Quantity | TQFP | Number of Positions | 100 |
| Shell Size - Insert | 1 | Number of Cores/Bus Width | 16 Bit |
Product Info
| Series | H8® H8S/2300 | On-Chip RAM | 8-chx10-bit |
| Peripherals | POR, PWM, WDT | Architecture | CISC |
| Connectivity | SCI, SmartCard | Programmable | Yes |
| Accessory Type | POR, PWM, WDT | Core Processor | H8S/2000 |
| Number of Timers | 8 | RF Family/Standard | H8S |
| DigiKey Programmable | Yes | Printed Circuit Board | 100 |
Environmental
| Operating Temperature | -20 to 75 °C | Operating Temperature - Junction | 75C |
