RP30-243.3SEW
| Manufacturer | |
| Description | DC/DC Converters 30W DC/DC 1.6kV REG 4:1 9-36Vin 3.3Vout CONV DC/DC 30W 10-40VIN 3.3VOUT RP30-243.3SEW regulated DC-DC,3.3V 30W DC-DC,RP30-243.3SEW Recom RP30 EW 系列 隔离式直流-直流转换器 , 3.3V dc输出, 6A输出 ±0.5%负载调节 ±0.5%线路调节 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Isolated | Tradename | Powerline |
| Standard Package | 5 | ||
Compliance
| RoHS | Compliant | ||
Electrical
| Noise | 60mV | Efficiency | 87% |
| Power - Max | 30W | Output Power | 30 W |
| Power (Watts) | 87% | Power - Rated | 30W |
| Voltage Rating | 24V dc | Line Regulation | ±0.5% |
| Load Regulation | ±0.5% | Voltage - Input | 24 V |
| Current - Output | 6A | Voltage - Supply | 10 → 40 V 直流 |
| Number of Outputs | 1 | Power (Watts) - Max | 19.8W |
| Voltage - Isolation | 1.6kV (1600V) | Current Rating (Max) | 6A |
| Voltage - Input (Min) | 3.3V | Voltage Regulation - Load | ±0.5% |
| Current - Output / Channel | 7500 mA | ||
Mechanical
| Depth | 10.2mm | Width | 50.8mm |
| Height | 10.2 mm | Length | 40.6mm |
| Weight | 48g | Packaging | Tube |
| Mounting Type | Through Hole | Package / Case | 8-DIP Module (7 Leads) |
| Size / Dimension | 2.00" L x 1.60" W x 0.40" H (50.8mm x 40.6mm x 10.2mm) | ||
Product Info
| Type | Isolated Module | Series | RP30 |
| Features | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | Function | Y |
Environmental
| Operate Time | 1315000h | Operational Life | 1315000h |
| Operating Temperature | -40°C ~ 85°C | Maximum Temperature Limit | +85°C |
