RACT20-1050-US
| Manufacturer | |
| Description | LED SUPP CC AC/DC 12-18V 1.05A LED SUPPLY CC AC/DC 12-18V 1.05A LED Drivers Power Supplies 20W AC/DC-LED Power LIGHTLINE |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Switching Supplies | Tradename | Lightline |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | Approval Agency | CE, cULus |
Electrical
| Dimming | Triac | Efficiency | 81% |
| Output Power | 20 W | Power (Watts) | 20W |
| Operating Mode | Constant Current (CC) | Voltage Rating | 115 V |
| Current - Output | 1.05A | Number of Outputs | 1 |
| Voltage - Isolation | 3.75kV (3750V) | Voltage - Input (Min) | 12 ~ 18 V |
| Current - Output / Channel | 1050 mA | ||
Mechanical
| Weight | 0.32 lb (145.15g) | Mounting Type | Chassis Mount |
| Mounting Style | Chassis | Panel Mount Type | Enclosed |
| Size / Dimension | 5.41" L x 1.98" W x 0.91" H (137.5mm x 50.2mm x 23.0mm) | Termination Style | 5.5mm Socket, Screw Terminal |
Product Info
| Type | Constant Current | Series | RACT20 |
| Features | OTP, SCP | Topology | AC DC Converter |
| Application | Commercial | ||
Environmental
| Ratings | IP20 | Operating Temperature | -30°C ~ 50°C |
