RAC20-24SB
| Manufacturer | |
| Description | Linear and Switching Power Supplies 20W AC/DC 3kV REG 90-264Vin 24Vout AC/DC CONVERTER 90-264V TO 24V CONV AC/DC 20W 24V OUT SNGL T/H Power Supply,Encapsulated,PCB mt,24V 20W Switching Power Supplies 20W AC/DC 3kV REG 90-264Vin 24Vout CONVERTER, AC/DC, 20W, 3KV, 24V CONV AC/DC 20W 90-264VIN 24VOUT Recom 20W 单输出 嵌入式开关模式电源 SMPS , 90 → 264V ac输入, 24V dc输出, 833mA输出, 83%效能, 密封封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 8 | Product | Switching Supplies |
| Tradename | Powerline | Unit Pack | 8 |
| Standard Package | 8 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85044030 | Leadfree Defin | RoHS-conform |
| Approval Agency | CE, UL | Protection Features | Yes |
Electrical
| Noise | 100mV(pp) | Output | 24VDC@0.833A |
| Isolation | 3kV(AC) | Operation | Switching |
| Efficiency | 78% | Output Type | Single |
| Power - Max | :20W | Output Power | 20 W |
| Power (Watts) | 20W | Power - Rated | 20W |
| Power - Output | 20 W | Voltage Rating | 90-264V(AC) |
| Line Regulation | 0.5% | Load Regulation | 1% |
| Current - Output | 833mA | Number of Outputs | 1 |
| Power Supply Type | Switching (Closed Frame) | Power (Watts) - Max | 20W |
| Voltage - Isolation | 3 kV | Voltage - Input (Min) | 24V |
| Current - Output / Channel | 833 mA | Voltage - Continuous Operating (Max) (MCOV) | :264V |
Mechanical
| Depth | 23.5mm | Width | 27.2mm |
| Height | 23.5 mm | Length | 52.4mm |
| Weight | 0.13 lb (58.97g) | Packaging | BOX |
| Mounting Type | Through Hole | Mounting Style | Through Hole |
| Package Cooled | Encapsulated | Panel Mount Type | Enclosed |
| Primary Material | AC-DC | Size / Dimension | 2.06" L x 1.07" W x 0.94" H (52.4mm x 27.2mm x 23.8mm) |
Product Info
| Type | Industrial | Series | RAC-Series |
| Features | SCP | Matchcode | RAC20-24SB |
| Application | Commercial | Applications | Commercial |
| Manufacturer | RAC20-SB Series | Configuration | Encapsulated |
| Standard Leadtime | 11 weeks | ||
Environmental
| Operate Time | 250000h | Operating Temperature | -40°C ~ 70°C |
| Maximum Temperature Limit | +70°C | ||
