1.69.508.864/1301
| Manufacturer | |
| Description | SIGNAL LAMP, TRANSPARENT, RED LED Indicator red 24...28 VDC, 1.69.508.864/1301, RAFI |
| Category |
对参数有疑问？问 AI 助手
Compliance
| Tariff No | 85318095 | ||
Electrical
| Lamp Type | :5mm | Power - Rated | :120mW |
| Voltage - Supply | :28V | LED Forward Voltage | :28V |
| Current Rating (Max) | :12mA | Current - DC Forward (If) (Max) | :12mA |
Mechanical
| Weight | 0.00035 | LED Color | :Red |
| Lens Style | :Round | Size / Dimension | :5mm |
| Height Above Board | :1mm | Panel Cutout Shape | :5mm |
| Mounting Hole Diameter | :5mm | ||
