20-101-1105
| Manufacturer | |
| Description | System-On-Modules - SOM RCM4100 RabbitCore Module MODULE RCM4100 RABBITCORE Rabbit Semiconductor Rabbit 4000 CP 59MHz Core Module, 3 to 3.6V dc MODULE, RABBITCORE, RCM4100, SPI Rabbit 4000处理器 59MHz 核心模块, 3 → 3.6V dc |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | System-On-Modules - SOM | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 84733080 |
Electrical
| Speed | 58.98MHz | Memory | 512kB |
| RAM Size | 1MB | Core Type | :(Not Available) |
| Frequency | 59 MHz | Interface | Serial |
| Memory Size | 512 kB | Memory Type | Flash, SRAM |
| Voltage - Supply | 3 V to 3.6 V | Number of Elements | :RCM4100 |
| Available Frequency Range | Asynch, HDLC, IrDA, SDLC, SPI | ||
Mechanical
| Width | 36mm | Height | 12mm |
| Length | 48mm | Weight | 0.006 |
| Connector Type | IDC Header 2x25, 2x5 | Size / Dimension | 48 mm x 36 mm x 12 mm |
Product Info
| Type | Rabbit 4000 | Features | Analogue to Digital Converter, Input Capture, Pulse Width Modulator, Quadrature Decoder, Real Time Clock, Slave Interface, Timers, Watchdog Timer |
| Flash Size | 512 kB | Form Factor | RCM4100 |
| On-Chip RAM | 512 kB Fast SRAM, 512 kB SRAM | Kit Contents | :Board |
| Manufacturer | :RabbitCore | Accessory Type | :Core Module |
| Battery Series | Yes | Core Processor | Rabbit 4000 |
| Proto Board Type | Fast SRAM, SRAM | Module/Board Type | MPU Core |
| Chipset Manufacturer | :Rabbit Semiconductor | ||
Environmental
| Operating Temperature | + 85 C | ||
