LM2540-7
| Manufacturer | |
| Description | AC/DC Power Supply Dual-OUT 15V/15V 1.7A/1.7A 50W 11-Pin EURO-CASSETTE 50W 2X 15V EURO-CASSETTE50W2X15V |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | Approval Agency | CE, cULus, EN, IEC, TUV |
Electrical
| Frequency | 47 to 440 Hz | Efficiency | 78(Min) % |
| Power - Max | 50 W | Power (Watts) | 50W |
| Power - Input | Switching (Closed Frame) | Voltage Rating | 85 to 264 V |
| Line Regulation | ±60mV | Load Regulation | 60mV |
| Current - Output | 1.7(Typ)|1.7(Typ) A | Voltage - Supply | 15V, 15V |
| Number of Outputs | 2 | Power Supply Type | Switching (Closed Frame) |
| Power (Watts) - Max | 50W | Current Rating (Max) | 0.2(Typ) A |
| Voltage - Input (Min) | 15V, 15V | ||
Mechanical
| Size | 6.63" L x 4.38" W x 1.52" H (168.5mm x 111.2mm x 38.7mm) | Mounting Type | Chassis Mount |
| Size / Dimension | 6.63" L x 4.38" W x 1.52" H (168.5mm x 111.2mm x 38.7mm) | ||
Product Info
| Type | Switching | Series | M |
| Applications | Commercial | Output Configuration | Chassis Mount |
Environmental
| Operating Temperature | -25 to 71 °C | ||
