FNP1500-48G
| Manufacturer | |
| Description | AC/DC Power Supply Dual-OUT 48V/12V 32.2A/1A 1.512KW PWR SUP 1512W 48V FRONT END PowerSupply;AC-DC;48VDC@25.4A,12VDC@1A;85-264VACIn;Enclosed;RackMnt;Industrial |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Approval Agency | CE, cUL, EN, TUV, UL |
Electrical
| Output | 12VDC@1A,48VDC@32.2A | Frequency | 47 to 63 Hz |
| Operation | PFC | Efficiency | 90(Typ) % |
| Power - Max | 1512 W | Power (Watts) | 1500W |
| Power - Output | 1500W | Voltage Rating | 85 to 105|105 to 264 V |
| Current - Output | 32.2|1 A | Number of Outputs | 2 |
| Power Supply Type | Switching (Closed Frame) | Power (Watts) - Max | 1512W |
| Current Rating (Max) | 20(rms) A | Voltage - Input (Min) | 12V, 48V |
Mechanical
| Mounting Type | Rack Mount | Mounting Style | CageMount |
| Primary Material | AC-DC | Size / Dimension | 11.00" L x 1.60" W x 5.60" H (279.4mm x 40.5mm x 141.2mm) |
Product Info
| Type | Switching | Features | PFC |
| Applications | Commercial | Manufacturer | FNPSeries |
| Configuration | Enclosed | ||
Environmental
| Operating Temperature | 0 to 70 °C | ||
Documents & Media
PDF Document
