RDK-242
| Manufacturer | |
| Description | REFERENCE DESIGN FOR A 30 W SUPPLY Power Management IC Development Tools TOPSwitch-JX REF. DESIGN KIT KIT REF DESIGN VG TOPSWITCH-JX TOP266VG, PSU, 30W, EVAL BOARD |
| Category |
Business
| Product | Power Management Modules | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423990 | ||
Electrical
| Power - Output | 30W | Voltage Rating | 85 VAC to 264 VAC |
| Current - Output | 2.5A | Number of Elements | :TOP266VG |
| Regulator Topology | Flyback | Frequency - Switching | 132kHz |
| Voltage - Input (Min) | 12V | ||
Mechanical
| Weight | 0.002 | Packaging | Box |
| Board Thickness | Fully Populated | ||
Product Info
| Type | Power Drivers | Contents | Board |
| Features | :- | Kit Type | :Power Management |
| Kit Contents | :Eval Board TOP266VG | Main Purpose | AC/DC, Primary and Secondary Side |
| Outputs and Type | 1, Isolated | Utilized IC / Part | TOP266VG |
| Chipset Manufacturer | :Power Integrations | Application Specifics | :Power Supply |
