4290
| Manufacturer | |
| Description | RF Adapters - Between Series SMA M/BNC F Conn SMA-BNC Adapter PL/RCP 0Hz to 12.4GHz 50Ohm ST Gold ADAPTER SMA MALE-BNC FEMALE Adapter;SMAMaleToBNCFemale;TeflonPerL-P-403;0.59in.;Gold-Plated SMA (Male) to BNC (Female) Between Series Adapter |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | 1918210 | Product Category | RF Adapters - Between Series |
| Standard Package | 5 | Factory Pack Quantity | 6 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Frequency | 0 to 12.4 | Impedance | 50 Ohm |
| Voltage Rating | 335V | Conversion Type | Between Series |
| Frequency - Max | 12.4GHz | Frequency Range | DC to 12.4 GHz |
Mechanical
| Length | 1.02in. | Diameter | 15 mm |
| Packaging | Bulk | Body Finish | Gold; Nickel |
| Body Material | Beryllium Copper | Mounting Type | Straight |
| Shell Plating | Gold | Angle of Throw | Straight |
| Connector Type | SMA BNC | Contact Finish | Gold |
| Housing Finish | Gold | Plating - Body | Gold |
| Contact Material | Brass/Beryllium Copper | Housing Material | BerylliumCopper |
| Length - Overall | 26 mm | Overall Diameter | 0.59in. |
| Primary Material | Adapter | Mating Orientation | Bayonet |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Insulation Material | Polytetrafluoroethylene |
| 1st Connector Gender | Plug (Male) | 2nd Connector Gender | Jack (Female) |
| Center Contact Plating | Gold | Center Contact Material | Beryllium Copper; Brass |
| Supplier Device Package | Straight | 1st Connector Mounting Type | Normal |
Product Info
| Type | SMA-BNC Adapter | Style | Straight |
| Gender | PL/RCP | RF Type | BNC |
| Adapter Type | Plug to Jack | Manufacturer | Pomona |
| Product Type | Adapter | Center Gender | Female to Male |
| Adapter Series | BNC to SMA | Convert To (Adapter End) | BNC Jack, Female Socket |
| Convert From (Adapter End) | SMA Plug, Male Pin | ||
Environmental
| Operating Temperature | -65C to 165C | ||
