3925-9
| Manufacturer | |
| Description | Test Clips MINI TEST CLIP WH CLIP MINIGRABBER D-I-Y 10PC WHT Conn Test Clip 1 POS ST Cable Mount 1 Port TEST CLIP, 1POS Minigrabber,Pack/10,White |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Test Clips | Part # Aliases | 1924855 |
| Product Category | Test Clips | Standard Package | 1 |
| Factory Pack Quantity | 10 | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85369010 |
Electrical
| Voltage Rating | 30 V | Current Rating (Max) | 5 A |
Mechanical
| Color | White | Length | 56.69 mm |
| Weight | 0.036 | Tip Shape | :Hook |
| Jaw Opening | 3.05 mm | Termination | Solder, 0.090" (2.29mm) Wire Opening |
| Contact Finish | Gold | Contact Material | Beryllium Copper Alloy |
| Length - Overall | :2.35" | Number of Contacts | :1 |
| Insulation Material | Nylon | Hook, Pincer Opening | 0.090" (2.29mm) |
Product Info
| Type | Minigrabber clip | Series | :3925 |
| Features | :Do-It-Yourself | Function | Minigrabber test clip |
| Quantity | 10 | Hook Type | Hook |
Environmental
| Operating Temperature | + 102 C | ||
