3060267

点击放大查看

3060267

Category

Connector SolutionsTerminal BlocksTerminal Blocks and Connectors

对参数有疑问？问 AI 助手

Business

Tradename	CLIPLINE UT	Product Category	DIN Rail Terminal Blocks
Standard Package	50	Factory Pack Quantity	50

Compliance

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Material Flammability Rating	UL94 V-0

Electrical

Current - UL	30A	Voltage - UL	600V
Current - IEC	32A	Voltage - IEC	500V
Voltage Rating	500 V	Current Rating (Max)	32A
Voltage - Input (Min)	500V

Mechanical

Color	Gray	Depth	6.2
Width	6.2 mm	Height	55
Length	2.193" (55.70mm)	Weight	0.463500 oz
Wire Gauge	26 → 10 AWG	Termination	Screw
Height (Max)	2.165" (55.00mm)	Housing Color	Gray
Mounting Type	DIN Rail	Number of Rows	3
Housing Material	Polyamide	Length - Overall	55.7
Stripping Length	9mm	Terminal - Width	6.2mm
Termination Rows	插入式、螺钉拧紧	Termination Style	Plug Receptacles, Screw
Color - Connectors	Grey	Number of Contacts	3
Number of Positions	3	Material - Insulation	Polyamide (PA), Nylon
Wire Gauge or Range - AWG	10-26 AWG	Wire Gauge or Range - mm2	0.14-6mm²

Product Info

Type	Terminal Block	Gender	F
Series	UT	Number of Layers	单层
Number of Levels	1

Documents & Media

PDF Document

Sourcing & traceability

Datasheet: 3060267

Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
