2774017
| Manufacturer | |
| Description | DIN Rail Terminal Blocks 6.2mm DBL LVL GRAY 26-10AWG UKK5 Conn Terminal Block F 4 POS Screw 32A CONN TERM BLK FEED THRU 6.2MM Conn;TermBlk;DBLLevel;Screw;4;24-12AWG;Gray; Splice terminal: rail; ways:2; terminals:4; grey; 0.2÷4mm2; 32A Double-level terminal block - UKK 5 |
| Category |
Business
| Tradename | CLIPLINE UK | Product Category | DIN Rail Terminal Blocks |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Material Flammability Rating | UL94 V-0 | ||
Electrical
| Current - UL | 30A | Voltage - UL | 600V |
| Current - IEC | 32A | Voltage - IEC | 500V |
| Voltage - Test | 8kV | Voltage Rating | 500 V |
| Number of Poles | 2 | Connector Impedance | rail |
| Current Rating (Max) | 32 A | Voltage - Input (Min) | 500V |
Mechanical
| Color | Gray | Depth | 6.2 |
| Width | 6.2 mm | Height | 67 mm |
| Length | 56 mm | Weight | 0.543924 oz |
| Wire Gauge | 24 | Termination | Screw |
| Body Material | polyamide | Mounting Type | screw terminal |
| Mounting Rails | TS32, TS35 | Mounting Style | DIN Rail |
| Number of Rows | 4 | Housing Material | Polyamide |
| Length - Overall | 56 | Package Quantity | 50 |
| Stripping Length | 8mm | Terminal - Width | 6.2mm |
| Termination Rows | 螺钉 | Termination Style | Screw |
| Wire Strip Length | 8mm | Color - Connectors | grey |
| Number of Contacts | 4 | Number of Positions | 4 |
| Material - Insulation | Polyamide (PA), Nylon | Wire Gauge or Range - AWG | 10-26 AWG |
| Wire Gauge or Range - mm2 | 0.2-4mm² | Contact Finish Thickness - Post | 6.2mm |
Product Info
| Mfr | 0.2-4mm² | Spg | 50 |
| Type | Terminal Block | Gender | F |
| Series | UK | Number of Units | 1 |
| Number of Levels | 2 | ||
Documents & Media
Similar Parts
1004115
Phoenix Contact
Terminal Block Tools & Accessories WS 3- 6 Warning Plate, With 2 Plastic Screws, Across 3 Terminal Blocks LABEL WARNING SIGN 6MM Warning label WS 3- 6 WARNINGPLATE,PITCH6MM
5029125
