1914629
| Manufacturer | |
| Description | Pluggable Terminal Blocks DFK-MSTB 2.5/ 3-G- 5,08 BK Misc Products TERM BLOCK DFK-MSTB25/3-G-508BK |
| Category |
Business
| Product | Headers | Tradename | COMBICON Control |
| Other Names | DFK-MSTB 2 5/ 3-G-5 08 BK | Product Category | Pluggable Terminal Blocks |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current - UL | 10A | Voltage - UL | 300V |
| Voltage Rating | 320 V | Current Rating (Max) | 12 A |
Mechanical
| Color | Black | Pitch | 5.08 mm |
| Width | 1.400" (35.56mm) | Weight | 5.820204 oz |
| Contact Finish | Tin | Mounting Style | Panel / Box - Feed Through |
| Panel Thickness | 0.020 ~ 0.158" (0.5 ~ 4.0mm) | Panel Mount Type | Screw Mount - Front Flange |
| Number of Contacts | 3 | Rear Panel Wire Connection | Quick Connect - 0.110" (2.80mm), Solder Eyelet |
| Front Panel Wire Connection | Header, Male Pins | ||
Product Info
| Series | DFK-MSTB | Features | Lock Opening |
| Number of Levels | 1 | Positions Per Level | 3 |
Similar Parts
1755477
Phoenix Contact
Terminal Block Tools & Accessories MSTB-BL Connector Accessories Cap TERMINAL BLOCK KEYING CAP GREEN Keying cap, for forming sections, plugs onto header pin, green insulating material Keying Cap, For Forming Sections, Plugs Onto Header Pin MSTB-BL
1759990
Phoenix Contact
Pluggable Terminal Blocks IC 2.5/ 3-G-5.08 BK HEADER NOMINAL CURRENT 12A NUMBER OFPOSITIONS 3 TERM BLOCK HDR 3POS R/A 5.08MM IC25/3-G-508BK
1902738
Phoenix Contact
Pluggable Terminal Blocks IC 2.5/ 3-G-5.08 ABGY TERM BLOCK HDR 3POS R/A 5.08MM IC25/3-G-508ABGY
1734401
Phoenix Contact
Terminal Block Tools & Accessories CODING ELEMENT PRICED PER CLIP Connector Accessories Coding Element Inserted Into The Recess In The Header Or The Inverted Plug Red TERM BLOCK HEADER CODING ELEMENT CR-MSTB CODINGSECTION,REDINSULATINGMATERIAL
0708263
Phoenix Contact
Terminal Block Tools & Accessories HDR HDWR FOR 5.08mm ORDER QTY 2 PER HDR Connector Accessories Screw Set HDWR SET 3X10 SCREW/WASHER/NUT
5030172
Phoenix Contact
Terminal Block Tools & Accessories LOCKING LATCH Connector Accessories Locking Latch Red LOCKING LATCH RED MSTB PCB terminal stop notches DFK-MSTB-R
1786417
