Business

Standard Package50

Compliance

RoHSLead free / RoHS CompliantEU RoHSCompliant
Approval AgencyUL,cULus,CSA

Electrical

Current20AVoltage600V
Voltage Rating600VNumber of Poles2Poles
Current Rating (Max)30AVoltage - Input (Min)1000V

Mechanical

ColorGreenDepth35.5
Pitch0.300" (7.62mm)Height19.7
PackagingBulkWire Gauge10-30 AWG
TerminationScrewMounting TypeCable Mount
Contact FinishTinNumber of Rows1
Plug Wire Entry180°Housing MaterialPolyamide
Length - Overall15.22Primary MaterialPCB
Pin Hole Diameter7.62mmNumber of Contacts2
Number of Positions2Terminal Block TypePlug, Female Sockets
Wire Entry LocationFront

Product Info

TypeTerminal BlockLevelSingleLevel
GenderFFeaturesRetention Latches (Non-Wire Side)
ManufacturerCombiconNumber of Levels1
Base Product NumberPC4HV/2-ST-7,62Positions Per Level2

Documents & Media

PDF Document

Sourcing & traceability

Datasheet
1848892

Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
