1844359
| Manufacturer | |
| Description | Pluggable Terminal Blocks MC 1 5/16-G-3 5 Conn Shrouded Header HDR 16 POS 3.5mm Solder RA Thru-Hole TERM BLOCK HDR 16POS R/A 3.5MM Header for PCB plug connector MC 1,5/16-G-3,5 Header, Nominal current: 8 A, Nom. voltage: 160 V, Pitch: 3.5 mm, Number of positions: 16, Color: green, Assembly: Soldering MC15/16-G-35 Phoenix Contact COMBICON MC 系列 16路 3.5mm节距 PCB 接线端子块 , 焊接端接, 8A |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Headers | Tradename | COMBICON Control |
| Standard Pack | 50 | Product Category | Pluggable Terminal Blocks |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current | 8A | Voltage | 300V |
| Voltage Rating | 160 V | Current Rating (Max) | 8 A |
| Voltage - Input (Min) | 160V | ||
Mechanical
| Color | Green | Depth | 9.2 |
| Pitch | 0.138" (3.50mm) | Height | 7.25 |
| Weight | 4 oz | Packaging | Bulk |
| Termination | Solder | Housing Color | Green |
| Mounting Type | Right Angle | Contact Finish | Tin |
| Number of Rows | 1 | Contact Material | 锡 |
| Housing Material | Polybutylene Terephthalate | Length - Overall | 57.4 |
| Termination Rows | 焊接 | Termination Style | Through Hole |
| Header Orientation | 90°, Right Angle | Number of Contacts | 16 |
| Number of Positions | 16 | Terminal Block Type | Header, Male Pins, Shrouded (4 Side) |
Product Info
| Type | Shrouded Header | Gender | HDR |
| Series | MC | Number of Levels | 1 |
| Positions Per Level | 16 | ||
