点击放大查看
1843363
| Manufacturer | |
| Description | Pluggable Terminal Blocks MCV1.5/16/GF-3.5 Conn Wire to Board HDR 16 POS 3.5mm Solder ST Thru-Hole TERM BLOCK HDR 16POS VERT 3.5MM Header for PCB plug connector MCV 1,5/16-GF-3,5 MCV15/16-GF-35 Phoenix Contact COMBICON MCV 系列 16路 3.5mm节距 PCB 接线端子块 , 焊接端接, 8A |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Headers | Tradename | COMBICON Control |
| Product Category | Pluggable Terminal Blocks | Standard Package | 50 |
| Factory Pack Quantity | 50 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current | 8A | Voltage | 300V |
| Voltage Rating | 160 V | Current Rating (Max) | 8 A |
| Voltage - Input (Min) | 160V | Voltage - Supply (Min) | 160V |
Mechanical
| Color | Green | Depth | 7.25 mm |
| Pitch | 0.138" (3.50mm) | Height | 9.2 mm |
| Weight | 0.162260 oz | Packaging | Bulk |
| Termination | Solder | Housing Color | Green |
| Mounting Type | Straight | Contact Finish | Tin |
| Mounting Style | Through Hole | Number of Rows | 1 |
| Contact Material | 锡 | Housing Material | Polybutylene Terephthalate |
| Length - Overall | 66.3 mm | Termination Rows | 焊接 |
| Termination Style | Through Hole | Header Orientation | Vertical |
| Number of Contacts | 16 | Number of Positions | 16 |
| Terminal Block Type | Header, Male Pins, Shrouded (4 Side) | ||
Product Info
| Type | Wire to Board | Gender | HDR |
| Series | MCV | Features | Flange |
| Number of Levels | 1 | Positions Per Level | 16 |
