1773336

点击放大查看

1773336

Category

Connector SolutionsHeavy Duty ConnectorsHeavy Duty Connectors

对参数有疑问？问 AI 助手

Business

Lead Time	24 Days	Tradename	HEAVYCON
Other Names	HC-HV 3-ESTC	Subcategory	Connector Rectangular
Product Category	Circular Metric Connectors	Standard Package	1
Factory Pack Quantity	1

Compliance

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Material Flammability Rating	UL94 V-0

Electrical

Voltage Rating	250 V	Current Rating (Max)	16A
Voltage - Input (Min)	690V

Mechanical

Size	B10	Weight	1.868462 oz
Packaging	Bulk	Termination	Crimp
Contact Type	CK 2.5-ED	Mounting Type	Straight
Connector Type	Insert without Contacts	Contact Finish	Silver
Number of Rows	2	Contact Material	Copper Alloy
Housing Material	Polyamide	Termination Style	Crimp
1st Contact Gender	M	Number of Contacts	3
Number of Positions	3+2+Ground

Product Info

Type	HEAVYCON Insert	Gender	Male
Polarity	5P+E	Accessory Type	触点插件
Industry Aliases	HC-HV 3-ESTC

Environmental

Operating Temperature

-40°C ~ 125°C

Documents & Media

Online Document

Online Document

PDF Document

Sourcing & traceability

Datasheet: 1773336

Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
