Business

Lead Time20 DaysTradenameHEAVYCON
SubcategoryConnector Terminal BlocksProduct CategoryHeavy Duty Power Connectors
Standard Package1Factory Pack Quantity1

Compliance

RoHSLead free / RoHS CompliantEU RoHSCompliant
Material Flammability RatingUL94 V-0

Electrical

Voltage Rating600VCurrent Rating (Max)10A
Voltage - Input (Min)250V

Mechanical

SizeD64Depth36
Height33.8Weight3 oz
PackagingBulkWire Gauge14-26
TerminationCrimpContact TypeCK 1.6-ED
Mounting TypePanel MountConnector TypeInsert without Contacts
Contact FinishSilverNumber of Rows2
Insertion ForceMaleContact MaterialCopper Alloy
Housing MaterialPolyamideLength - Overall110
Termination StyleCrimpNumber of Contacts64
Number of Positions64Wire Gauge or Range - AWG26-14

Product Info

TypeTerminal BlockGenderF
SeriesHeavyconProduct TypeInserts
Industry AliasesHC-D 64-ESTC

Environmental

Operating Temperature-40°C ~ 125°C

Documents & Media

PDF Document

Sourcing & traceability

Datasheet
1772528

Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
