1766275
| Manufacturer | |
| Description | Pluggable Terminal Blocks 6P HEADER Conn Shrouded Header HDR 6 POS 7.62mm Solder RA Thru-Hole TERM BLOCK HDR 6POS R/A 7.62MM Header for PCB plug connector GMSTBA 2,5/ 6-G-7,62 GMSTBA25/6-G-762 Phoenix Contact COMBICON GMSTBA 系列 6路 7.62mm节距 PCB 接线端子块 , 焊接端接, 12A |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Headers | Lead Time | 20 Days |
| Tradename | COMBICON Control | Subcategory | Connector Headers and PCB Receptacles |
| Product Category | Pluggable Terminal Blocks | Standard Package | 100 |
| Factory Pack Quantity | 50 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Current | 10A | Voltage | 300V |
| Voltage Rating | 400 V | Current Rating (Max) | 12 A |
| Voltage - Input (Min) | 630V | Voltage - Supply (Min) | 630V |
Mechanical
| Color | Green | Depth | 12 mm |
| Pitch | 0.300" (7.62mm) | Height | 8.6 mm |
| Weight | 6.172943 oz | Packaging | Bulk |
| Termination | Solder | Housing Color | Green |
| Mounting Type | Right Angle | Contact Finish | Tin |
| Mounting Style | Through Hole | Number of Rows | 1 |
| Contact Material | 锡 | Housing Material | Polyamide |
| Length - Overall | 45.72 mm | Termination Rows | 焊接 |
| Termination Style | Through Hole | Header Orientation | 90°, Right Angle |
| Number of Contacts | 6 | Number of Positions | 6 |
| Terminal Block Type | Header, Male Pins, Shrouded (4 Side) | ||
Product Info
| Type | Shrouded Header | Gender | HDR |
| Series | GMSTBA | Industry Aliases | GMSTBA 2, 5/ 6-G-7, 62 |
| Number of Levels | 1 | Positions Per Level | 6 |
Documents & Media
PDF Document
PDF Document
Similar Parts
1767041
Phoenix Contact
Pluggable Terminal Blocks 6P 7.62MM PITCH Conn Terminal Block F 6 POS 7.62mm Screw RA Cable Mount 12A TERM BLOCK PLUG 6POS STR 7.62MM Printed-circuit board connector GMSTB 2,5/ 6-ST-7,62 Conn Terminal Blocks F 6 POS 7.62mm Screw RA Cable Mount 12A PLUGCOMPONENT,PITCH:7.62MM,POS6 Phoenix Contact COMBICON GMSTB 系列 7.62mm 节距 6 路 母 绿色 直 插头, 插入式, 螺钉端接
$100.6400
Details
1832455
