1688609
| Manufacturer | |
| Description | Modular Connectors / Ethernet Connectors VS-08-BU-RJ45/LP-4 Conn RJ-45 F 32 POS 2.54mm Solder RA Thru-Hole 32 Terminal 4 Port Cat 5e CONN MOD JACK R/A 8P8C SHIELDED RJ45 socket insert, 4x, for PCB assembly, CAT5e, 8-pos., shielded, with angled solder pins VS-08-BU-RJ45/LP-4 |
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | PLUSCON Data | Standard Package | 1 |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current Rating (Max) | 1.5 A | ||
Mechanical
| Depth | 22 | Pitch | 2.54 |
| Height | 14 | Weight | 1 oz |
| LED Color | Does Not Contain LED | Packaging | Bulk |
| Shielding | Shielded | Orientation | 90° Angle (Right) |
| Termination | Solder | Mounting Type | Through Hole |
| Tab Direction | Down | Connector Type | Jack |
| Contact Finish | Gold Over Nickel | Number of Rows | 1 |
| Contact Material | Copper Alloy | Housing Material | Thermoplastic |
| Length - Overall | 59.79 | Termination Style | SMD |
| Number of Contacts | 32 | ||
Product Info
| Type | RJ-45 | Gender | F |
| Features | Board Guide | Category Number | Cat 5e |
| Number of Ports | 4 | Number of Positions Loaded | 32 |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) | ||
Environmental
| Ratings | Cat5e | Ingress Protection | IP20 |
| Operating Temperature | -40°C ~ 85°C | ||
