1688599
| Manufacturer | |
| Description | モジュラーコネクタ/Ethernetコネクタ VS-08-BU-RJ45/LP-2 Conn RJ-45 F 8 POS 2.54mm Solder RA Thru-Hole 8 Terminal 1 Port Cat 5e CONN MOD JACK R/A 8P8C SHIELDED Modular Connectors / Ethernet Connectors VS-08-BU-RJ45/LP-2 VS-08-BU-RJ45/LP-2 |
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | PLUSCON Data | Standard Package | 1 |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current Rating (Max) | 1.5 A | ||
Mechanical
| Depth | 22 | Pitch | 2.54 |
| Height | 14 | Weight | 0.677260 oz |
| LED Color | Does Not Contain LED | Packaging | Bulk |
| Shielding | Shielded | Orientation | 90° Angle (Right) |
| Termination | Solder | Mounting Type | Through Hole |
| Tab Direction | Down | Connector Type | Jack |
| Contact Finish | Gold Over Nickel | Number of Rows | 1 |
| Contact Material | Copper Alloy | Housing Material | Thermoplastic |
| Length - Overall | 31.85 | Termination Style | SMD |
| Number of Contacts | 8 | ||
Product Info
| Type | RJ-45 | Gender | F |
| Features | Board Guide | USOC Codes | RJ45 |
| Category Number | Cat 5e | Number of Ports | 1 |
| Number of Positions Loaded | 16 | Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
Environmental
| Ratings | Cat5e | Ingress Protection | IP20 |
| Operating Temperature | -40°C ~ 85°C | ||
