0404046
| Manufacturer | |
| Description | Fixed Terminal Blocks AK 35 Conn Power Terminal Blocks F Screw ST 125A TERM BLK CONNCT L/N/PE W/O CAP TerminalBlock;PickOff;ScrewConnection;125A;Silver |
| Category |
Business
| Product | Fixed Terminal Blocks | Lead Time | 28 Days |
| Subcategory | Connector Terminal Blocks | Product Category | Fixed Terminal Blocks |
| Standard Package | 50 | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | Material Flammability Rating | UL94 V-2 |
Electrical
| Current - UL | 115A | Voltage - UL | 300V |
| Current - IEC | 125A | Current Rating (Max) | 125 A |
Mechanical
| Color | Silver | Depth | 14.3 mm |
| Width | 14.3 mm | Length | 1.063" (27.00mm) |
| Wire Gauge | 14 | Termination | Screw |
| Mounting Type | Straight | Number of Rows | 1 |
| Housing Material | Polyamide | Length - Overall | 27 mm |
| Stripping Length | 16mm | Terminal - Width | 14.3mm |
| Termination Style | Screw | Number of Contacts | 1 |
| Number of Positions | 1 | Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 2-18 AWG | Wire Gauge or Range - mm2 | 2.5-35mm² |
Product Info
| Type | Power Terminal Blocks | Gender | F |
| Series | AK | Industry Aliases | AK 35 |
| Number of Levels | 1 | ||
Documents & Media
Similar Parts
0824992
Phoenix Contact
Terminal Block Tools & Accessories ZB 6 CUS TERM BLOCK MARKING LABEL Terminal Block Tools & Accessories ZB 6 CUS 1 strip is 1 piece TERMINALBLOCKMARKING
1051003
Phoenix Contact
Terminal Block Tools & Accessories 6.2mm BLANK STRIPS OF TEN MARKERS EACH Single Covers, Color Transparent CONN ACC MARKER STRIP UNPRINTED Phoenix Contact 1051003 Marker Strip Terminal Block, Series: ZB ZACK STRIP, UNPRINTED ZBMarkingStrip;TermBlk;6.2mm;Blank;White Marker; Width:6mm; for labelling by user Phoenix Contact ZB 系列 标记条
0818085
Phoenix Contact
Unspecified Tools & Accessories UC-TM 6 UNICARD 80 SECTION Connector Accessories Terminal Block Marker Polyamide White UNICARD SHEETS 1 ROLL=80 LABELS Terminal Block Tools & Accessories UC-TM 6 UNICARD 80 SECTION MarkerCard;TermBlk;6.2mm;80labelspercard;white Phoenix Contact UC-TM 6 系列 端子标记
0404431
Phoenix Contact
Terminal Block Tools & Accessories AB2/SS DINRAIL BUSBAR SUPPORT DOUBLE Double Support, Insulating Material, Optionally For Use With 3mm X 10mm Or 6mm X 6mm BUSBar BusbarSupport;for(3x10,6x10)mmBusbars
3032431
