6TPE100MPB
| Manufacturer | |
| Description | CAP TANT 100UF 6.3V 20% 1411 Capacitor Tantalum TPE series 6.3V 100uF Tantalum Capacitors - Polymer SMD 6.3volts 100uF ESR 25mohm Cap Tant Solid 100uF 6.3V B2 CASE 20% (3.5 X 2.8 X 1.9mm) SMD 3528 0.025 Ohm 105C Embossed T/R CAP, TANT, 100UF, 6.3V, CASE B2 Capacitor,Tantalum,6.3VDC,100uF,25mohm,T&R Panasonic POSCAP 系列 100μF ±20% SMD 钽电容器, 6.3 V, B2 封装, 25mΩ ESR, +85°C |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Tantalum Organic Polymer Low ESR | Tradename | POSCAP |
| Standard Pack | 2,000 | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85322200 |
| Rad Hardened | No | ||
Electrical
| Voltage | 6.3 V | Tolerance | ±20% |
| Capacitance | 100µF | Range deg/s | :PANASONIC - TPE Series |
| Voltage Rating | 6.3 V | Current - Leakage | 63 μA |
| DC Cold Resistance | 63 uA | Capacitance - Input | :1411 [3528-20 Metric] |
| Dielectric Constant | 8% | Resistance Tolerance | -20% |
| Dissipation Factor (DF) | 8 | Ripple Current @ High Frequency | 1600 mA |
| ESR (Equivalent Series Resistance) | 25mΩ | ||
Mechanical
| Seal | Not Required | Depth | 2.8mm |
| Width | 2.8 mm | Height | 1.9mm |
| Length | 3.5mm | Weight | 0.0001 |
| Diameter | Not Required mm | Packaging | Reel |
| Insulation | Not Required | Construction | SMT Chip |
| Height (Max) | Not Required mm | Lead Spacing | Not Required mm |
| Mounting Type | Surface Mount | Mounting Style | Surface Mount |
| Package / Case | B2 | Material Finish | :- |
| Length - Overall | Not Required mm | Size / Dimension | 3.5 x 2.8 x 1.9mm |
| Material - Insulation | Solid | Mounting Hole Diameter | 3528 |
| Wire Gauge or Range - AWG | Not Required | ||
Product Info
| Series | TPE | Polarity | Polar |
| Failure Rate | Not Required | Manufacturer | B2 Case |
| Manufacturer Size Code | :B2 | ||
Environmental
| Operating Temperature | +85°C | ||
