LT4HW-DC24VS
| Manufacturer | |
| Description | Timers TIMER SCREW 24VDC TIMER DIGITAL 24VDC SCREW TERM Digital Timer, 24VDC, 11-Pin Terminal TIMER, TIMER, SCREW, 24VDC |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | Q1140702 | Product Category | Timers |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85364900 | ||
Electrical
| Output | :1 Changeover Relay | Circuit | SPDT (1 Form C) |
| Delay Time | 0.01 Sec ~ 9999 Hrs | Output Type | Mechanical Relay |
| Range deg/s | :PANASONIC - LT4HW Series | Delay Time - ON | :0.01s |
| Number of Poles | :1 | Delay to 1st Tap | :99.99s to 9999h |
| Voltage - Supply | 12 ~ 24VDC | Connector Impedance | :Screw Terminals |
| Current Rating (Max) | :5A | Voltage - Input (Max) | :24V |
| Timing Initiate Method | Input Voltage | Contact Rating @ Voltage | 5A @ 250VAC |
Mechanical
| Depth | :65mm | Width | :45mm |
| Length | :48mm | Weight | 0.15 |
| Packaging | Bulk | Mounting Type | Panel Mount |
| Termination Style | Screw Terminal | Contact Layout, Typical | :SPDT |
| Panel Cutout Dimensions | :45mm | ||
Product Info
| Series | :LT4H-W | Function | Programmable (Multi-Function) |
| Relay Type | Integrated | Adjustment Type | :Pushbutton |
| Digits or Characters | :4 | Other Specifications | :9999h |
| Timing Adjustment Method | Up/Down Digit Keys | ||
Environmental
| NEMA Frame Size | :IP66 | Operating Range | :0.01s - 9999h |
