APV1121S
| Manufacturer | |
| Description | Photodiode Output Optocouplers 2500VAC 8.7V DRIVER Optocoupler DC-IN 1-CH Linear Photovoltaic DC-OUT 4-Pin SOP T/R OPTOCOUPLER PHOTOVO 2.5KVRMS SMD SSR, MOSFET, 0.05A, 2.5KV PhotovoltaicMOSFETDriver,4-pinSOP, |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 255-2656 | Product Category | Photodiode Output Optocouplers |
| Standard Package | 100 | Factory Pack Quantity | 100 |
| Standard Package Name | SOIC | ||
Compliance
| RoHS | RoHS Compliant By Exemption | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85364110 |
| Rad Hardened | No | ||
Electrical
| Output | Photovoltaic | Input Type | DC |
| Output Type | DC | Load Current | :14µA |
| Power - Rated | 0.075 W | Voltage - Supply | Not Required V |
| Number of Channels | 1 Channel | Number of Elements | 1 |
| LED Forward Current | 3 mA | LED Forward Voltage | 1.5 V |
| Voltage - Breakdown | 5 V | Voltage - Isolation | 2500 Vrms |
| Vce Saturation (Max) | Not Required V | Voltage - Input (Min) | 8.7V |
| Power Dissipation (Max) | 75 mW | Voltage Regulation - Load | 5 |
| Current - Input Bias (Max) | 50 | Current - Output / Channel | 14µA |
| Current Transfer Ratio (Min) | Not Required % | Current - Collector (Ic) (Max) | Not Required A |
| Current - DC Forward (If) (Max) | :50mA | Current - Collector Cutoff (Max) | Not Required A |
| Voltage - Reverse Standoff (Typ) | 5 V | Voltage - Forward (Vf) (Max) @ If | 1.5 V |
| Current - Average Rectified (Io) (per Diode) | 50mA | ||
Mechanical
| Width | 4.4 | Weight | 0.002 |
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Package / Case | SOP-4 |
| Package Cooled | SOP | Length - Overall | 4.3 |
| Package Quantity | SOP | Number of Positions | 4 |
| Shell Size - Insert | 2.1 | Contact Layout, Typical | :- |
Product Info
| Series | APV1 | Relay Type | :SMD |
| Printed Circuit Board | 4 | ||
Environmental
| Operating Temperature | + 85 C | ||
