AGN260A24
| Manufacturer | |
| Description | Low Signal Relays - PCB 2 Form C High Sense Coil Voltage 24 RELAY TELECOM DPDT 1A 24V Electromechanical Relay DPDT 1A 24VDC 4.8KOhm Surface Mount RELAY;GeneralPurpose;IndustrialRelay;DPDT;2FormCHighSenseCoilVoltage24 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 255-2611 | Product Category | Low Signal Relays - PCB |
| Standard Package | 50 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | ||
Electrical
| Coil Type | Single Side Stable | Coil Power | 120 mW |
| Coil Current | 5mA | Release Time | 4ms |
| Coil Resistance | 4.8 kOhms | Voltage - Supply | 24 VDC |
| Switching Voltage | 125VAC, 110VDC - Max | Vgs(th) (Max) @ Id | 2.4 VDC |
| Power - Average Forward | 120 mW | Vce(on) (Max) @ Vge, Ic | 19.2 VDC |
| Contact Rating (Current) | 1A | ||
Mechanical
| Packaging | Tube | Contact Form | 2 Form C (DPDT-BM) |
| Mounting Type | Surface Mount | Contact Material | Silver Palladium (AgPd), Gold (Au) |
| Termination Style | Gull Wing | ||
Product Info
| Function | Sensitive | Relay Type | Telecom |
Environmental
| Operate Time | 4ms | Operating Temperature | -40°C ~ 70°C |
