MTM861270LBF
| Manufacturer | |
| Description | MOSFET PCH MOS FET FLT LD 1.6x1.6mm MOSFET P-CH 20V 2A WSSMINI6 Trans MOSFET P-CH 20V 2A 6-Pin WSSMini6-F1 MOSFET, P-CH, 20V, 2A, WSSMINI6 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | MTM861270LBFTR | Standard Package | 10,000 |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85412900 |
Electrical
| FET Type | MOSFET P-Channel, Metal Oxide | Vgs (Max) | :-4V |
| FET Feature | Standard | Power - Max | 540mW |
| Transistor Type | P-Channel | Vgs(th) (Max) @ Id | 1.1V @ 1mA |
| Voltage - Threshold | :-750mV | Current Rating (Max) | :-2A |
| Resistance - RDS(On) | :120mohm | Rds On (Max) @ Id, Vgs | 120 mOhm @ 1A, 4V |
| Power Dissipation (Max) | :540mW | Vce(on) (Max) @ Vge, Ic | - 20 V |
| Drain to Source Voltage (Vdss) | 20V | Current - Drain (Idss) @ Vds (Vgs=0) | - 2 A |
| Input Capacitance (Ciss) (Max) @ Vds | 300pF @ 10V | Current - Continuous Drain (Id) @ 25degC | 2A (Ta) |
Mechanical
| Weight | 0.0001 | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :6 | Package / Case | 6-SMD, Flat Leads |
| Material Finish | :MSL 1 - Unlimited | Supplier Device Package | WSSMini6-F1 |
Product Info
| Configuration | Single | ||
Environmental
| Operating Temperature | :-40°C | ||
Documents & Media
PDF Document
