ML-621S/DN
| Manufacturer | |
| Description | Lithium Coin 3V 5mAh Rechargeable BATTERY LITH COIN 3V RECHARGE Coin Cell Battery 3V 5.0 mAh RECHG 2PIN FLAT SMT-NO INS Battery;CoinCell;Lithium;Rechargeable;PCBTabs;3V;5mAh LITH 3V 5MAH leadfree |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | ML-621S/DN | Product Category | Coin Cell Battery |
| Standard Package | 400 | Factory Pack Quantity | 400 |
Compliance
| RoHS | Lead free / RoHS compliant by exemption | EU RoHS | RoHS Not Applicable |
| Automotive | NO | Leadfree Defin | Leadfree |
| Approval Agency | UN 38.3 | ||
Electrical
| Memory | No | Voltage | 3V |
| Capacity | 5mAh | Discharge Rate | 10µA |
| Voltage Rating | 3V | Number of Cells | 1 |
| Standard Charge Current | 600µA | Current - Supply (Main IC) | 0.01 |
Mechanical
| Size | Coin/Button | Shape | Coin |
| Height | 2.1mm | Weight | 0.01 oz (0.28g) |
| Diameter | 6mm | Packaging | TRAY |
| Contact Type | bare cell | Primary Material | Rechargeable |
| Size / Dimension | 0.27" Dia x 0.09" H (6.8mm x 2.2mm) | Termination Style | SMD (SMT) Tab |
Product Info
| Form | COIN | Type | Rechargeable Coin Cell Battery |
| Features | Rechargeable | Technology | LITH |
| Manufacturer | ML-ManganeseLithium | Shipping Info | Due to possible restrictions, a change in ship method may be required. |
| Battery Series | ML621 | Battery Cell Size | Coin, 6.8mm |
| Battery Chemistry | Secondary | Battery Type, Function | Rechargeable |
Environmental
| Temperature | -20 TO 60 °C | Operating Temperature | - 20 C to + 60 C |
