EVQ-P7A01K
| Manufacturer | |
| Description | Switch Tactile N.O. SPST Rectangular Button Gull Wing 0.05A 12VDC 2.2N SMD Embossed Tape SWITCH TACTILE SPST-NO 0.05A 12V Switch; Tactile; SPST; 3.5x2.9mm Right Angle PCB mnt; OF=2.2N; Hgt=1.35mm |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | P12277SCT | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Circuit | SPST-NO | Voltage Rating | 12 V |
| Switch Function | Off-Mom | Current Rating (Max) | 0.05@12VDC A |
| Switch Function/Rating | N.O. | Contact Rating @ Voltage | 0.05A @ 12VDC |
Mechanical
| Outline | 3.50mm x 2.90mm | Packaging | Tape & Reel (TR) |
| Actuator Type | Rectangular Button | Mounting Type | Surface Mount |
| Switch Travel | 0.20mm | Terminal Type | Gull Wing |
| Operating Force | 2.2 N | Termination Style | Gull Wing |
| Actuator Orientation | Side Actuated | Switch Actuation Level | SPST |
Product Info
| Type | Light Touch | Illumination | Non-Illuminated |
Environmental
| Mechanical Life | 100,000 Cycles | Operating Temperature | -20 to 70 °C |
