EVN-D2AA03B15
| Manufacturer | |
| Description | TRIMMER POT,CARBON,6MM SQ.,SIDE ADJ. ,DUSTPROOF,100K OHMS Res Carbon Composition Trimmer 100K Ohm 0.1W(1/10W) 1(Elec)/1(Mech)Turn 3.2mm (6.4 X 4.65 X 8mm) Pin Thru-Hole Bulk TRIMMER 100K OHM 0.1W TH Trimmer Resistors - SMD TRIMMER POT.:CARBON 6MM SQ.SIDE ADJ. TRIMMER, 100KOHM, 1TURN, TH Trimmer; Carbon; Rest 100 Kilohms; PCB; 1 Turn; Pwr-Rtg 0.1 W; Linear; Side Adj; 6 mm SQ |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Trimmer Resistors - SMD | Lead Time | 77 Days |
| Subcategory | Resistor Trimmers, Potentiometer and Rheostat | Standard Package | 500 |
| Factory Pack Quantity | 5000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85334010 | ||
Electrical
| Tolerance | ±30% | Resistance | 100 Kilohms |
| Power (Watts) | 0.1W, 1/10W | Power - Rated | :100mW |
| Resistance (Ohms) | 100k | Power - Peak Pulse | 0.1 W |
| Resistance Tolerance | :- | DC Resistance (DCR) (Max) | :100kohm |
Mechanical
| Depth | 4.65 | Taper | Linear |
| Height | 8 | Weight | 0 |
| Packaging | Bulk | Mounting Type | Through Hole |
| Shaft Diameter | 3.2 | Material - Core | Carbon |
| Length - Overall | 6.4 | Size / Dimension | Square - 0.252" L x 0.177" W x 0.307" H (6.40mm x 4.50mm x 7.80mm) |
| Termination Style | Pin | Resistive Material | Carbon |
Product Info
| Type | Trimmer | Technology | Carbon Composition |
| Manufacturer | EVN-D2A | Product Type | Single Turn |
| Adjustment Type | Side Adjustment | Number of Turns | Single |
| Industry Aliases | EVND2AAO3B15 | ||
Environmental
| Mechanical Life | 210 Deg. | Temperature Coefficient | :- |
