ERZ-V20D471
| Manufacturer | |
| Description | Var 300VAC 385VDC 10000A 470V Thru-Hole Bulk Varistors 300V 100A CLAMP Var 300VAC/385VDC 10000A 470V Radial Bulk VARISTOR 470V 6.5KA DISC 20MM ZNR Transient/Surge Absorbers; Type D V Series 20 mm 300 VAC 385 VDC 10000 A 470 V Through Hole Varistor |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | MOV | Product Category | Varistors |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Voltage | 300 VAC | Capacitance | 900 pF |
| Power - Output | 250J | Voltage Rating | 385 V |
| Current - Surge | 10000 A | Maximum AC Volts | 300VAC |
| Maximum DC Volts | 385VDC | Voltage - Clamping | 775 V |
| Voltage - Rated AC | 300V | Current - Peak Output | 10000 A |
| Voltage - Input (Min) | 300 V | Varistor Voltage (Max) | 470 V |
| Varistor Voltage (Min) | 470 V | Current - Peak Pulse (8/20us) | 100 A |
| Voltage - DC Spark Over (Nom) | 385V | ||
Mechanical
| Depth | 6.6 mm | Height | 24.5 mm |
| Diameter | 20 mm | Packaging | Bulk |
| Lead Style | Radial | Size - Body | Not Required |
| Lead Spacing | 10 mm | Pitch - Post | 10 |
| Mounting Type | Radial | Mounting Style | Leaded |
| Package / Case | Disc 20mm | Primary Material | Varistor |
| Size / Dimension | 20 mm Dia. | Termination Style | Radial |
Product Info
| Type | Through Hole | Energy | 250J |
| Series | V | Technology | Metal Oxide |
| Manufacturer | ZNR Series | Number of Circuits | 1 |
| Other Specifications | 423V | ||
Environmental
| Mechanical Life | End of Life: Scheduled for obsolescence and will be discontinued by the manufacturer. | Surge Rating (Watts) | 350 J |
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85 °C |
