ERZ-V14D391
| Manufacturer | |
| Description | Var 250VAC 320VDC 6000A 390V Thru-Hole Bulk Varistors 250V 50A CLAMP Var 250VAC/320VDC 6000A 390V Radial Bulk VARISTOR 390V 4.5KA DISC 14MM ZNR Transient/Surge Absorbers; Type D |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | MOV | Lead Time | 105 Days |
| Subcategory | Varistor | Product Category | Varistors |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Voltage | 250 VAC | Capacitance | 500 pF |
| Power - Output | 100J | Voltage Rating | 320 V |
| Current - Surge | 6000 A | Maximum AC Volts | 250VAC |
| Maximum DC Volts | 320VDC | Voltage - Clamping | 650 V |
| Current - Peak Output | 6000 A | Voltage - Input (Min) | 250 V |
| Varistor Voltage (Max) | 390 V | Varistor Voltage (Min) | 390 V |
| Current - Peak Pulse (8/20us) | 50 A | Voltage - DC Spark Over (Nom) | 320VDC |
Mechanical
| Depth | 5.8 | Height | 18.5 |
| Diameter | 14 mm | Packaging | Bulk |
| Lead Style | Radial | Lead Spacing | 7.5 mm |
| Pitch - Post | 7.5 | Mounting Type | Radial |
| Mounting Style | Leaded | Package / Case | Disc 14mm |
| Primary Material | Varistor | Size / Dimension | 14 mm Dia. |
| Termination Style | Radial | ||
Product Info
| Type | Through Hole | Energy | 100J |
| Series | V | Technology | Metal Oxide |
| Manufacturer | ZNR Series | Industry Aliases | ERZV14D391 |
| Number of Circuits | 1 | Other Specifications | 351V |
Environmental
| Surge Rating (Watts) | 140 J | Operating Temperature | -40 to 85 °C |
| Operating Temperature - Junction | 85 °C | ||
