ERJ-3EKF1783V
| Manufacturer | |
| Description | Res Thick Film 0603 178K Ohm 1% 1/10W ±100ppm/°C Molded SMD SMD Punched Carrier T/R Thick Film Resistors - SMD 0603 178Kohms 1% Tol Res Thick Film 0603 178K Ohm 1% 0.1W(1/10W) ±100ppm/°C Molded SMD Punched Carrier T/R RES 178K OHM 1/10W 1% 0603 SMD Thick Film Resistors 0603 178Kohms 1% Tol Res Thick Film 0603 178K Ohm 1% 0.1W(1/10W) ?100ppm/C Molded SMD Punched Carrier T/R Resistor; Thick Film; Res 178 Kilohms; Pwr-Rtg 0.1 W; Tol 1%; SMT; 0603 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Thick Film Resistors SMD | Other Names | P178KHDKR |
| Standard Package | Cut Tape | Factory Pack Quantity | 5000 |
Compliance
| RoHS | RoHS Compliant By Exemption | EU RoHS | Compliant |
| Military Standard | Not Required | ||
Electrical
| Tolerance | 1 % | Fail Short | No |
| Resistance | 178 KOhm | Power - Max | 1/10 W |
| Power (Watts) | 0.1W, 1/10W | Power - Rated | 1/10 W |
| Voltage Rating | 75 V | Current - Sensing | No |
| Resistance (Ohms) | 178k | Power - Peak Pulse | 0.1 W |
Mechanical
| Depth | 0.8 mm | Width | 0.8 mm |
| Height | 0.022" (0.55mm) | Packaging | Reel |
| Termination | SMT | Construction | Rectangular |
| Mounting Type | Surface Mount | Contact Finish | Tin |
| Package / Case | 0603 | Package Cooled | 0603 (1608 mm) |
| Material - Core | Thick Film | Length - Overall | 1.6 mm |
| Size / Dimension | 0.8 mm W x 1.6 mm L x 0.45 mm H | Termination Style | SMD/SMT |
| Mounting Hole Diameter | 0603 | Number of Terminations | 2 |
| Supplier Device Package | 0603 | ||
Product Info
| Type | Thick Film | Series | ERJ |
| Features | Precision | Technology | Thick Film |
| Composition | Thick Film | Failure Rate | Not Required |
Environmental
| Temperature Range | –55 to +155 °C | Surge Rating (Watts) | No |
| Operating Temperature | -55 to 155 °C | Temperature Coefficient | ±100 ppm/°C |
