ECQ-V1474JM
| Manufacturer | |
| Description | Cap Film 0.47uF 100V PET 5% (10.2 X 6.8 X 10.5mm) Radial 7.5mm 105°C Bulk Film Capacitors .47uF 100V 5% CAP FILM 0.47UF 100VDC RADIAL Cap Film 0.47uF 100V PET 5% (10.2 X 6.8 X 10.5mm) Radial 7.5mm 105C Bulk Capacitor; Polyester Metallized; Cap 0.47uF; Tol 5%; Vol-Rtg 100 VDC; Radial; STR; Blk |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Metallized Plastic Film Capacitors | Lead Time | 91 Days |
| Subcategory | Capacitor Plastic Film | Product Category | Film Capacitors |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Voltage | 100 Vdc | Tolerance | 5 % |
| Capacitance | 0.47 uF | Voltage Rating | 100 V |
| Dissipation Factor (DF) | 1 | ||
Mechanical
| Size | 10.2 X 6.8 X 10.5 | Depth | 6.8(Max) mm |
| Width | 6.8 mm | Height | 10.5(Max) mm |
| Diameter | Not Required mm | Packaging | Bulk |
| Lead Style | Straight | Termination | PC Pins |
| Construction | Radial | Height (Max) | 11.5 mm |
| Lead Spacing | 7.5 mm | Pin Diameter | 0.5 mm |
| Pitch - Post | 7.5 mm | Mounting Type | Through Hole |
| Mounting Style | Through Hole | Package / Case | 10.2(Max) X 6.8(Max) X 10.5(Max) |
| Material - Core | Polyester Metallized | Length - Overall | 10.2(Max) mm |
| Size / Dimension | 0.402" L x 0.268" W (10.20mm x 6.80mm) | Termination Style | Radial |
| Diameter - Outside | 0.5 mm | Dielectric Material | PET |
| Height - Seated (Max) | 0.433" (11.00mm) | Diameter - Small Outside | 0.5 mm |
Product Info
| Type | Radial | Series | ECQV(L)(M) |
| Applications | General Purpose | Failure Rate | Not Required |
| Manufacturer | ECQV Series | Product Type | AC Pulse, Suppression |
| Industry Aliases | ECQV1474JM | ||
Environmental
| Temperature Range | –40 to 105 °C | Operating Temperature | -40 to 105 °C |
| Temperature Coefficient | PET | Operating Temperature - Junction | 105 °C |
