OD4010-12LS01A
| Manufacturer | |
| Description | FAN 40X10MM 12V TACH |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | OD401012LS01A | Standard Package | 40 |
Electrical
| Noise | 14 dB | Voltage Range | 7 ~ 14VDC |
| Voltage Rating | 12VDC | Current Rating (Max) | 0.060A |
Mechanical
| RPM | 4200 RPM | Air Flow | 5.0 CFM (0.142m³/min) |
| Fan Type | Tubeaxial | Termination | 3 Wire Leads |
| Bearing Type | Sleeve | Static Pressure | 0.060 in H2O (14.9 Pa) |
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Size / Dimension | Square - 40mm L x 40mm H x 10.5mm W | ||
Product Info
| Features | Speed Sensor (Tach) | ||
Environmental
| Rated Life | 30000 hrs @ 45°C | Operating Temperature | -4 ~ 176°F (-20 ~ 80°C) |
Documents & Media
PDF Document
