OVQ12S30G7
| Manufacturer | |
| Description | LED Lighting Strips Green, 525nm Flexible Strip LED LT STRIP FLEX GRN TR=10UNITS LED LT STRIP FLEX GRN 1 UNIT |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | LED Flexible Strips | Lead Time | 70 Days |
| Other Names | 365-1502-2 | Subcategory | LED Modules |
| Product Category | LED Lighting Strips | Standard Package | 10 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Voltage | 12V | Optic Size | 3.2 mm x 2.8 mm |
| Wavelength | 525nm | Power - Rated | 2.3 W |
| Current - Output | 133mA | Driver Circuitry | Yes |
| LED Forward Voltage | 12 V | Current Rating (Max) | 133mA |
| Wavelength - Dominant | 525 nm | ||
Mechanical
| Color | Green | Width | 8 mm |
| Length | 500 mm | Packaging | Reel |
| Mounting Style | Adhesive | Connector Usage | No |
| Illumination Color | Green | ||
Product Info
| Illumination | 50 lux | Configuration | Flex Ribbon |
| Number of LEDs | 30 | ||
Environmental
| Luminous Flux @ Current/Temperature | 50lux | ||
