OP297A
| Manufacturer | |
| Description | LED IrLED 890nm 2-Pin T-1 3/4 LED T-1 3/4 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package Name | T-1 3/4 | ||
Compliance
| RoHS | RoHS Compliant Part | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Lamp Output | No | Power - Rated | 1110 W |
| Viewing Angle | 20 deg | Wavelength - Peak | 890 nm |
| Number of Elements | 1 | Current - Trip (It) | 10 mA |
| LED Forward Current | 150 mA | LED Forward Voltage | 1.75 V |
| Power Dissipation (Max) | 1110 | Current - Peak Pulse (10/1000us) | 150 |
| Voltage - Gate Trigger (Vgt) (Max) | 5 V | ||
Mechanical
| Depth | 5.97 mm | Shape | Circular |
| Height | 8.64 mm | Lead Style | Through Hole |
| Lens Style | Circular | Lens Diameter | 4.95x4.95x7.62 mm |
| Mounting Type | Through Hole | Mounting Style | Top Mount |
| Package Cooled | T-1 3/4 | Material - Core | GaAlAs |
| Length - Overall | 5.97 mm | Package Quantity | T-1 3/4 |
| Diameter - Outside | 5.97 | Number of Positions | 2 |
| Shell Size - Insert | 8.64 | ||
Product Info
| Type | IrLED | Main Purpose | IrLED |
| Number of LEDs | 1 | Printed Circuit Board | 2 |
Environmental
| Operating Temperature | -40C to 100C | ||
Documents & Media
PDF Document
