FWDRM09-15S-K1444
| Manufacturer | |
| Description | Waterproof 15way D-Sub rear mount Socket D-Sub socket 15P, FWDRM09-15S-K1444, FCT |
| Category |
对参数有疑问？问 AI 助手
Electrical
| Voltage - Test | 1000 | Number of Poles | 15 |
| Current Rating (Max) | 3A | ||
Mechanical
| Depth | 4.5mm | Width | 21mm |
| Length | 40mm | Body Color | 25.0 |
| Termination | Solder Cup / Solder lug | Mounting Type | Straight |
| Contact Finish | Gold over Nickel | Contact Material | Copper Alloy |
| Housing Material | Brass | Size / Dimension | 40 x 21 x 4.5mm |
| Number of Contacts | 15 | Insulation Material | Thermoplastic, glass filled (UL 94 V-0) |
| 1st Connector Gender | Female | ||
Product Info
| Gender | Female | Series | FWD |
| Amplifier Type | 40.0 | ||
Environmental
| Operating Temperature | 70°C | ||
