SS-01T
| Manufacturer | |
| Description | Basic / Snap Action Switches Subminiature Basic Switch SWITCH BASIC SPDT .1A .110QC SPDT-NO/NC Pin Plunger Microswitch, 0.1 A @ 125 V ac, 0.1 A @ 30 V dc Switch Snap Action N.O./N.C. SPDT Pin Plunger Quick Connect 0.1A 125VAC 30VDC 1.47N Screw Mount MICROSWITCH, 0.1A, Microswitch; without lever; SPDT; 0.1A/125VAC; 0.1A/30VDC; IP40 Snap Action Switches Unsealed Actuator Type : Pin Plunger Construction: Unsealed Contact Configuration : SPDT Contact Rating : 0.1A, 125 VAC Service Life (Electrical): 200K Oper. Min. Service Life (Mechanical): 30M Oper. Min Switch Type : Snap Action Termination Configuration : Tab Terminal SWITCH SNAP LEVER Micro switch 0.1 A Plunger 1 change-over (CO), SS-01T, Omron Electronic Components Omron 单刀双掷 - 常开/常闭 引脚柱塞 微动开关, 100 mA @ 30 V 直流 |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 171 Days | Other Names | SS01T |
| Subcategory | Switch Snap Action | Part # Aliases | 1829508 382427 |
| Product Category | Basic / Snap Action Switches | Standard Package | 500 |
| Factory Pack Quantity | 500 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85365007 | ||
Electrical
| Circuit | SPDT | Voltage Rating | 125 V |
| Switch Function | On-Mom | Switching Voltage | ON-(ON) |
| Contact Resistance | 50mΩ | Differential Travel | 0.004" (0.1mm) |
| Current Rating (Max) | 0.1 A | Current - Max/Contact | :100mA |
| Insulation Resistance | 100MΩ | Switch Function/Rating | :(Not Applicable) |
| Contact Rating (Current) | 0.1 A @ 125 V ac, 0.1 A @ 30 V dc | Connector - Voltage Input | :Quick Connect, Solder |
| Voltage - Supply (Vcc/Vdd) | :30V | AC contacts rating (at resistance load) | 0.1 A / 125 VAC |
| DC contacts rating (at resistance load) | 0.1 A / 30 VDC | Voltage - Rated AC (Phase to Ground/Neutral) | :125V |
Mechanical
| Weight | 0.0016 | Packaging | Bulk |
| Pretravel | 0.020" (0.5mm) | Lead Style | 2.8x0.5mm connectors |
| Overtravel | 0.020" (0.5mm) | Size - Body | 19.8 x 6.4 x 10.2mm |
| Contact Form | SPDT | Actuator Type | Plunger, Pin |
| Mounting Type | Chassis Mount | Release Force | 25gf |
| Terminal Type | Tab | Operating Force | 150 g |
| Contact Material | Gold Alloy | Pitch - Connector | 7.3mm |
| Termination Style | Quick Connect | Actuator Style/Size | :Pin Plunger |
| Number of Positions | 1-position | Switch Actuation Level | :Subminiature |
| Contact Layout, Typical | SPDT-NO/NC | Torque - Rated (oz-in / mNm) | 1.47N |
Product Info
| Series | SS | CAD Drawing | 3D CAD Model |
| Switch Type | microswitch | Electrical Life | 200,000 Cycles |
| Number of Units | 1 | Switch Features | without lever |
| Industry Aliases | SS-01T | Operating Position | 0.330" (8.4mm) |
| Contacts Configuration | SPDT | ||
Environmental
| Seal Rating | IP40 | Mechanical Life | 30,000,000 Cycles |
| Ingress Protection | IP40 | Operating Temperature | -25°C ~ 85°C |
