D6F-10A6-000
| Manufacturer | |
| Description | Flow Sensors MEMS AIRFLOW SENSOR UP TO 50slpm LW PWR AIRFLOW SENSOR MEMS 10L/MIN Flow Sensor Mass Air/N2O/O2 ±3% 3-Pin SENSOR, MASS FLOW, MEMS, 0-10 LPM SENSOR;MEMSAIRFLOW;AIR,N2O,O2;0-10LPM;BUILT-INORIFICE,STRAIGHTCONNECT Sensor: gas flow; Usup:10.8÷26.4VDC; Range:0÷10 l/min; -10÷60°C Sensor Flow Sensor Sensing Range: 0-10 LPM Flow Sensor Typr: Air |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 95 Days | Subcategory | Flow Sensor |
| Part # Aliases | 1573145 657730 D6F10A6-000 | Product Category | Flow Sensors |
| Standard Package | 1 | Factory Pack Quantity | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85444290 | ||
Electrical
| Accuracy | +/- 3 % Full Scale | Sensor Type | MEMS Air Flow |
| Sensing Range | 0 ~ 10 LPM | Operating Mode | direct measurement |
| Voltage Rating | 1...5V DC | Current - Output | :15mA |
| Voltage - Supply | 12 V to 24 V | Analog Input:Output | 1 V to 5 V |
| Connector Impedance | :0.25" | Voltage - Input (Min) | 10.8 V ~ 26.4 V |
| Voltage - Output (Max) | :5.7VDC | Voltage - Output (Min/Fixed) | :0VDC |
Mechanical
| Depth | :30mm | Width | :78mm |
| Length | :30mm | Weight | 0.10256 |
| Air Flow | :0l/min to 10l/min | Port Size | 0.196"(5mm) |
| Flow (CFM) | :10l/min | Flow (SCFM) | :10l/min |
| Pressure (PSI) | :72.5psi | Material - Body | Thermoplastic resin / Aluminum alloy |
| Primary Material | AirFlow | ||
Product Info
| Type | MEMS Mass Flow Sensor | Series | D6F-10A, D6F-20A, D6F-50A |
| Function | AirFlow | Port Style | :Straight |
| Technology | MEMS | Measuring Range | :0l/min to 10l/min |
| Number of Units | 1 | Flow Sensor Type | Air |
| Output Configuration | analogue | Application Specifics | air |
Environmental
| NEMA Frame Size | :IP40 | Operating Range | 0 L/min to 10 L/min |
| Operating Temperature | :60°C | ||
