FCSL90R002GER
| Manufacturer | |
| Description | Current Sense Resistors - SMD 4watt .002ohm 2% Metal Foil RES 0.002 OHM 4W 2% 9045 WIDE Res Metal Foil 1835 0.002 Ohm 2% 4W ±100ppm/°C Epoxy Resin Wide Terminal SMD T/R Resistor; Metal Foil; Res 0.002 Ohms; Pwr-Rtg 4 W; Tol 2%; SMT; Current Sense |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | FCSL90R002GERTR | Product Category | Current Sense Resistors - SMD |
| Standard Package | 1,000 | Factory Pack Quantity | 1000 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Tolerance | 2 % | Resistance | 2 mOhms |
| Power (Watts) | 4W | Power - Rated | 4 W |
| Resistance (Ohms) | 0.002 | Power - Peak Pulse | 4 W |
Mechanical
| Width | 8.9 mm | Height | 0.028" (0.70mm) |
| Packaging | Reel | Termination | SMT |
| Package / Case | 0.7 mm | Material - Core | Metal Foil |
| Size / Dimension | 8.9 mm W x 4.5 mm L x 0.7 mm H | Termination Style | SMD/SMT |
| Mounting Hole Diameter | 1835 (Reversed) | Number of Terminations | 2 |
| Supplier Device Package | 9045 | ||
Product Info
| Series | FCSL | Features | Current Sense |
| Composition | Metal Foil | ||
Environmental
| Operating Temperature | - 55 C to + 155 C | Temperature Coefficient | 100 PPM / C |
Documents & Media
PDF Document
