PRTR5V0U2AX.215
| Manufacturer | |
| Description | ESD Suppressor Diode Arrays 12KV 4-Pin(3+Tab) SOT-143B T/R ESD Suppressors 5.5V DUAL R-R ESD ULTRA LOW CAP TVS DIODE 5.5VWM SOT143B TVS Diode Uni-Directional PRTR5V0U2AX,215 Quint, SOT-143B 4-Pin PRTR5V0U2AX@215 TVS diode, 5.5 V SOT-143B, PRTR5V0U2AX,215, NXP NXP 单向 TVS 二极管, 4针 SOT-143B封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 568-4139-1 | Part # Aliases | PRTR5V0U2AX T/R |
| Product Category | ESD Suppressors | Standard Package | 3,000 |
| Factory Pack Quantity | 3000 | ||
Compliance
| RoHS | RoHS Compliant | ESD Protection | 12@Contact Disc kV |
Electrical
| Capacitance | 16(Typ) pF | Voltage Rating | 5.5 V |
| Voltage - Supply | 5.5V (Max) | Number of Elements | 2 |
| Voltage - Breakdown | 9 V | Voltage - Off State | 5.5V |
| Current Rating (Max) | 100µA | Power Line Protection | Yes |
| Bidirectional Channels | 2 | Capacitance @ Frequency | 1.8pF @ 1MHz |
| Current - Reverse Leakage @ Vr | 0.1 uA | Voltage - Reverse Standoff (Typ) | 5.5 |
Mechanical
| Width | 1.4mm | Height | 1.1mm |
| Length | 3mm | Packaging | Reel |
| Mounting Type | Surface Mount | Number of Pins | 4 |
| Package / Case | SOT-143-B | Package Quantity | SOT-143B |
| Size / Dimension | 3 x 1.4 x 1.1mm | Termination Style | Gull Wing Leads |
| Number of Positions | 4 | Supplier Device Package | SOT-143B |
Product Info
| Type | Diode Arrays | Design | 2 Channel |
| Polarity | Bi-directional | Diode Type | 复杂阵列 |
| Applications | HDMI | Port Direction | Uni-Directional |
Environmental
| Operating Temperature | -40 °C | Maximum Temperature Limit | +85 |
