PESD5V2S2UT,215
| Manufacturer | |
| Description | ESD Suppressor TVS 30KV 3-Pin TO-236AB T/R TVS DIODE 5VWM 20VC SOT23 TVS Diode Uni-Directional PESD5V2S2UT,215 Dual 20V, 260W, TO-236AB 3-Pin TVS Diode Arrays 5V QUAD ESD PROTECT ULTRA LOW CAP PESD5V2S2UT@215 NXP 单向 TVS 二极管, 260W, 20V, 3针 TO-236AB封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 568-4060-1 | Part # Aliases | PESD5V2S2UT T/R |
| Product Category | TVS Diode Arrays | Standard Package | Tape & Reel |
| Factory Pack Quantity | 3000 | Standard Package Name | SOT-23 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ESD Protection | 30@Contact Disc/10@HBM |
Electrical
| Channels | 2 Channels | Capacitance | 200 pF |
| Voltage Rating | 5.2 V | Current - Surge | 15 A |
| Voltage - Supply | 5V (Max) | Current - Leakage | 1uA |
| Voltage - Working | 5.2V | Number of Elements | 2 |
| Power - Peak Pulse | 260W | Voltage - Clamping | 20 V |
| Current - Trip (It) | 5 mA | Voltage - Breakdown | 6.4V |
| Power Line Protection | No | Voltage - Supply (Min) | 5.2 V |
| Capacitance @ Frequency | 152pF @ 1MHz | Unidirectional Channels | 2 |
| Current - Peak Pulse (8/20us) | 15 A | Current - Reverse Leakage @ Vr | 1 uA |
| Current - Peak Pulse (10/1000us) | 15A (8/20µs) | Voltage - Reverse Standoff (Typ) | 5.2 V |
Mechanical
| Depth | 1.4 mm | Width | 1.4(Max) |
| Height | 1 mm | Packaging | Tape and Reel |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Locking Feature | TVS | Length - Overall | 3 mm |
| Package Quantity | TO-236AB | Size / Dimension | 1.4 mm W x 3 mm L x 1.1 mm H |
| Termination Style | SMD/SMT | Number of Positions | 3 |
| Shell Size - Insert | 1(Max) | Supplier Device Package | SOT-23-3 |
Product Info
| Type | TVS | Series | PESDxS2UT |
| Polarity | Unidirectional | Applications | General Purpose |
| Configuration | Dual Common Anode|Single | Port Direction | Uni-Directional|Bi-Directional |
| Printed Circuit Board | 3 | ||
Environmental
| Operating Temperature | -65 °C | Operating Temperature - Junction | 150C |
