PESD5V0U4BF,115
| Manufacturer | |
| Description | TVS Diode Arrays Diode TVS Quad Bi-Dir 5V 6-Pin ESD Suppressor TVS 10KV 6-Pin XSON T/R TVS DIODE 5VWM 6XSON |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 568-4810-1 | Standard Package | 5,000 |
| Factory Pack Quantity | 5000 | Standard Package Name | SON |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| ESD Protection | 10@Contact Disc/8@HBM | ||
Electrical
| Channels | 4 Channels | Capacitance | 2.9 pF |
| Voltage Rating | 5 | Voltage - Supply | 5V (Max) |
| Number of Elements | 4 | Voltage - Breakdown | 6.5 V |
| Power Line Protection | No | Bidirectional Channels | 4 |
| Capacitance @ Frequency | 2.9pF @ 1MHz | Current - Reverse Leakage @ Vr | 0.1 |
Mechanical
| Width | 1.05(Max) | Packaging | Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | SOT-886 |
| Length - Overall | 1.5(Max) | Package Quantity | XSON |
| Size / Dimension | 0.5 mm W x 1.02 mm L x 0.65 mm H | Termination Style | SMD/SMT |
| Number of Positions | 6 | Shell Size - Insert | 0.46(Max) |
| Supplier Device Package | 6-XSON, SOT886 (1.45x1) | ||
Product Info
| Type | TVS | Series | PESD5V0U4B |
| Polarity | Bidirectional | Applications | Ethernet |
| Configuration | Quad | Port Direction | Bi-Directional |
| Printed Circuit Board | 6 | ||
Environmental
| Operating Temperature | - 55 C | ||
